Connecting Rod compatible for Toyota Celica compatible for Corolla compatible for Lexus 2ZZ-GE 1.8L Conrod

  • * H-Beam con rods compatible for Toyota Corolla T-Sport Celica GT-S 2ZZGE 2ZZ-GE 1.8L​
  • * Advertised Horsepower Rating: 600-800HP
  • * Material: Forged 4340 aircraft chrome moly quality steel
  • * Dimensions: Center to center length: 138mm; Big end diameter: 48mm; Small end diameter: 20mm ( tapered small end); Big end width: 19.8mm; Small end width: 18mm
  • * Package Contents: 4 Pieces of H-Beam Connecting Rods; 8 Pieces of ARP 2000 3/8" Bolts (Note: Extra cost for upgrading to ARP L19 bolts)
  • * Performance Con Rods
  • * Advertised RPM Rating: 7000-9000 rpm
  • * Fastener Tensile Strength (psi):200,000 - 230,000 psi
  • * Balanced to within +/- 1 gram per end
  • * The big end bores are honed to a +/-.01mm tolerance
  • * Heat-treating & Shot-peened for remained consistent and strong
Stock In Stock
Item Number 3002032201

MORE OPTIONS

Combination offer

  • A
  • B
  • C
  • D
  • E
  • F
  • G
CR-TOY-138A-20
CR-TOY-138A-20
High Quality Components
High Quality Components
With Standard ARP 2000 Bolts(Upgradable ARP L19)
Precision Machining Manufacturing
Precision Machining Manufacturing
Shot Peening for improved fatigue life. 100% CNC machined for superior tolerances, Precision rod cap alignment dowels
Professional H-Beam Design
Professional H-Beam Design
Improve stiffness, reduce stress risers and reduce weight
High Performance Material
High Performance Material
Forged 4340 aircraft chrome moly quality steel for racing

Application

Compatible for Toyota Celica GT-S 2ZZGE 2ZZ-GE 1.8L​
Compatible for Toyota Corolla T-Sport 2ZZGE 2ZZ-GE 1.8L​
Compatible for Lotus Elise 2ZZGE 2ZZ-GE 1.8L​
Compatible for Lotus Exige 2ZZGE 2ZZ-GE 1.8L​
Compatible for Lotus Eleven 2ZZGE 2ZZ-GE 1.8L​

Note

- Professional installation is highly recommended (No Instruction Included)
- Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.

Specification

Performance Con Rods
Type: Forged 4340 aircraft chrome moly quality steel for racing
H-beam Conrods Quantity: 4 Pieces a set
Bolts:Including Genuine ARP 2000 bolts
Note: Extra cost for upgrading to ARP L19 bolts
Bolts Size: ARP 2000 3/8" bolts
Tolerance: Balanced to +/- 1 gram in set
Piston Bolt Hole: +-4/1000mm
Power: 600hp ~ 800PS per set
Strength of the fastening (PSI): 220,000/230,000 PSI Torque: 48ft ≈ 65 NM
Top acceleration: 9000rpm
warranty: one year warranty for any manufacturing defect

Dimensions

Center to center length: 138mm
Big end diameter:48mm
Small end diameter: 20mm
Big end width: 19.8mm
Small end width: 18mm

Feature

- Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing
- Designed and processed by CNC machine.
- All big and small ends are finished with SUNNEN honing machine
- Precision alignment sleeves positively locate the rod cap, maintaining big end bore size and eliminating cap walk
- 100% X-rayed, sonic tested and magnafluxed
- Multi-stage heat treated
- Shot peened to relieve stress
- Come with the bronzed bushing suitable for the floating piston pin
