- * H-Beam con rods compatible for Toyota Supra JZA70, Mark II, Crown 1JZ-GTE 1JZ-GE 1JZ
- * Advertised Horsepower Rating: 600 ~ 800HP
- * Material: Forged 4340 aircraft chrome moly quality steel
- * Dimensions: Center to center length: 125.25mm; Big end diameter: 55mm; Small end diameter: 22mm ( tapered small end); Big end width: 25.9mm; Small end width: 25.9mm
- * Package Contents: 6 Pieces of H-Beam Connecting Rods; 8 Pieces of ARP 2000 3/8" Bolts (Note: Extra cost for upgrading to ARP L19 bolts)
- * Performance Con Rods
- * Advertised RPM Rating: 7000-9000 rpm
- * Fastener Tensile Strength (psi):200,000 - 230,000 psi
- * Balanced to within +/- 1 gram per end
- * The big end bores are honed to a +/-.01mm tolerance
- * Heat-treating & Shot-peened for remained consistent and strong
Compatible for Toyota Supra JZA70, Mark II, Crown 1JZ-GTE 1JZ-GE 1JZ
- Performance Con Rods
- Type: Forged 4340 aircraft chrome moly quality steel
- H-beam Conrods Quantity: 4 Pieces as showing in picture
- Bolts: Including ARP 2000 bolts
- Note: Extra cost for upgrading to ARP L19 bolts
- Bolts Size: ARP 2000 3/8" bolts
- Tolerance: Balanced to +/- 1 gram in set
- Piston Bolt Hole: +-4/1000mm
- Power: 600hp ~ 800PS per set
- Strength of the fastening (PSI): 220,000/230,000 PSI Torque: 48ft ≈ 65 NM
- Top acceleration: 7000 - 9000rpm
- Warranty: one year warranty for any manufacturing defect
Center to center length: 125.25mm
Big end diameter: 55mm
Small end diameter: 22mm
Big end width: 25.9mm
Small end width: 25.9mm
- Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing
- Designed and processed by CNC machine.
- All big and small ends are finished with SUNNEN honing machine
- Precision alignment sleeves positively locate the rod cap, maintaining big end bore size and eliminating cap walk
- 100% X-rayed, sonic tested and magnafluxed
- Multi-stage heat treated
- Shot peened to relieve stress
- Come with the bronzed bushing suitable for the floating piston pin
- Professional installation is highly recommended (No Instruction Included)
- Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
