- * 1.H-Beam con rods compatible for Peugeot 309 GTI 405 MI16 1.9L 16v S16 XU9J4
- * 2.Advertised Horsepower Rating: 600-800HP
- * 3. Forged 4340 aircraft chrome moly quality steel
- * 4.Dimensions: Center to center length: 143mm; Big end diameter: 53.69mm; Small end diameter: 22mm; Big end width: 22.45mm; Small end width: 22.45mm
- * 5.Package Contents: 4 Pieces of H-Beam Connecting Rods; 8 Pieces of ARP 2000 3/8" bolts (Note: Extra cost for upgrading to ARP L19 bolts)
- * 6.Performance Con Rods
- * 7.Advertised RPM Rating: 7000-9000 rpm
- * 8. Fastener Tensile Strength (psi):200,000 - 220,000 psi
- * 9.Balanced to within +/- 1 gram per end
- * 10.The big end bores are honed to a +/-.01mm tolerance
- * 11.Heat-treating & Shot-peened for remained consistent and strong
Combination offer
- A
- B
- C
- D
- E
- F
- G
![](/active/img/comb/icon_add.png)
- Description
- Reviews (2)
- Q & A ()
- ESTIMATE SHIPPING
- INSTALLATION
- Product Installation
- Technique Instruction
- Official App
![CR-PEU-143](https://www.cqggedm.com/brand-max/description/b2c/en-gb/rod/default/d1.jpg)
![CR-PEU-143](https://www.cqggedm.com/brand-max/description/b2c/en-gb/rod/default/d2.jpg)
![1. High Performance Material](https://www.cqggedm.com/brand-max/keyfeature/en-gb/rod/forged-rods-cr-4/default/kf(1).jpg)
![2.High Quality Components](https://www.cqggedm.com/brand-max/keyfeature/en-gb/rod/forged-rods-cr-4/default/kf(2).jpg)
![3.Professional H-Beam Design](https://www.cqggedm.com/brand-max/keyfeature/en-gb/rod/forged-rods-cr-4/default/kf(3).jpg)
![4.Precision Machining Manufacturing](https://www.cqggedm.com/brand-max/keyfeature/en-gb/rod/forged-rods-cr-4/default/kf(4).jpg)
Application
Compatible for Peugeot 309 GTI 405 MI16 1.9L 16v S16 XU9J4
Specification
Performance Con Rods
Type: Forged 4340 aircraft chrome moly quality steel for racing
H-beam Conrods Quantity: 4 Pieces a set
Bolts:Including Genuine ARP 2000 bolts
Note: Extra cost for upgrading to ARP L19 bolts
Bolts Size: ARP 2000 3/8" bolts
Tolerance: Balanced to +/- 1 gram in set
Piston Bolt Hole: +-4/1000mm
Power: 600hp ~ 800PS per set
Strength of the fastening (PSI): 220,000/230,000 PSI Torque: 48ft ≈ 65 NM
Top acceleration: 9000rpm
warranty: one year warranty for any manufacturing defect
Dimensions
Center to center length: 143mm
Big end diameter : 53,69mm
Small end diameter: 22mm
Big end width: 22.45mm
Small end width: 22.45mm
Feature
- Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing
- Designed and processed by CNC machine.
- All big and small ends are finished with SUNNEN honing machine
- Precision alignment sleeves positively locate the rod cap, maintaining big end bore size and eliminating cap walk
- 100% X-rayed, sonic tested and magnafluxed
- Multi-stage heat treated
- Shot peened to relieve stress
- Come with the bronzed bushing suitable for the floating piston pin
Note
- Professional installation is highly recommended (No Instruction Included)
- Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
