Compatible for Nissan Safari compatible for Patrol Y61 TD42TI 4.2L HT18-2 Direct Bolt Turbo Turbocharger M

Application

Compatible for NISSAN Safari Y60 4.2L D TD42T 93-97
compatible for NISSAN Safari/Compatible for Patrol Y61 4.2L D TD42T 97-10
compatible for NISSAN Civilian Bus W40 4.2L D TD42T 95-99
compatible for NISSAN Civilian Bus W41 4.2L D TD42T 99-04
compatible for FORD Maverick 4.2L D TD42T 88-94

OE/Part number

047-095,047-090,1047095,1047090,
1441162T00,14411-62T00,
1441151N00,14411-51N00,
1441109D60,14411-09D60,

Specification

Turbo Model:HT18-2, HT18-3
Engine:TD42, TD42TI
Cooling Type: Water & Oil Cooled
Bearing Type: Journal Bearing / Floating Bearing
Thrust bearings: 270 Degrees
Turbo Type:Individual
Universal Fitment: No
Finish: Matte
Condition:100% Brand New
Accessories: You will receive the parts exactly as shown in the picture above.
Package Size: 30x 27 x 24 cm
Package Weight: 8850 g

Package included

1xTurbocharger
1xFlange gaskets
2xOil/Water port gaskets

Feature

* Product Material
1. Turbine housing ：Ductile iron QT450-10- temperature resistant up to 700℃
2. Steel turbine wheel：K418 alloy - high oxidation stability and resistance up to 900℃
3. Compressor housing：ZL104 aluminum with lightweight
4. Compressor wheel/blades：Cast aluminium blades – superior air tightness & corrosion resistance

* Product Performance
1. OEM-quality and size with little modification
2. Rich experience in turbo production and own factory
3. High-Speed oil seal ring and Precision clearance

* Technology Advantage:
1. 100% balancing Test by TURBOTECHNICS VSR3
2. G3-min-Flow VNT Turbo testing
3. Advanced Actuator Tester/Programmer

Note

* Please confirm your original turbo PART NUMBER before Purchasing
* Professional installation is highly recommended
* Before installing the new turbocharger, the cause that led to the failure of the turbo must be analyzed and eliminated (e.g. insufficient oil supply, foreign bodies in the intake area, crankcase ventilation without function, etc.)!
