H-beam Connecting Rod compatible for Fiat Punto GT 1.4 1.6 Turbo Conrod Con Rods bielle

  • * 1.H-Beam con rods compatible for Fiat Punto GT 1.4 1.6L Turbo, compatible for Fiat Punto MK1 (176)1993-1999, compatible for Fiat Punto 176_ 1993-2000 Hatchback
  • * 2.Advertised Horsepower Rating: 600~800HP
  • * 3. Forged 4340 EN24 aircraft chrome moly quality steel
  • * 4.Dimensions: Center to center length: 128.52mm;Big end diameter: 48.63mm;Small end diameter: 22mm;Big end width: 25.40mm;Small end width: 25.40mm
  • * 5.Package Contents: 4 Pieces of H-Beam Connecting Rods; 8 Pieces of ARP 2000 3/8" bolts (Note: Extra cost for upgrading to ARP L19 bolts)
  • * 6.Performance Con Rods
  • * 7.Advertised RPM Rating: 7000-9000 rpm
  • * 8. Fastener Tensile Strength (psi):200,000 - 230,000 psi
  • * 9.Balanced to within +/- 1 gram per end
  • * 10.The big end bores are honed to a +/-.01mm tolerance
  • * 11.Heat-treating & Shot-peened for remained consistent and strong
Item Number 3002906942
Stock In Stock

Combination offer

  • A
  • B
  • C
  • D
  • E
  • F
  • G
CR-Compatible for FIAT-128.5
CR-Compatible for FIAT-128.5
1. High Performance Material
1. High Performance Material
Forged 4340 EN24 aircraft chrome moly quality steel for racing
2.High Quality Components
2.High Quality Components
With Standard ARP 2000 Bolts (Upgradable ARP L19)
3.Professional H-Beam Design
3.Professional H-Beam Design
Improve stiffness, reduce stress risers and reduce weight
4.Precision Machining Manufacturing
4.Precision Machining Manufacturing
Shot Peening for improved fatigue life. 100% CNC machined for superior tolerances,Precision rod cap alignment dowels

Overview

The connecting rod, also known as the con rod, is the part of the piston engine that connects the piston to the crankshaft.The connecting rod and the crank convert the reciprocating motion of the piston to the rotation of the crankshaft.The connecting rod needs to transfer compression force and tension from the piston and rotate at both ends.
This connecting rod is guaranteed to compatible for Fiat Punto GT 1.4-1.6L 16V Turbo H-Beam.This is a Newconnecting rod replacement and is the perfect OEM & aftermarket connecting rod.
The high strain of the connecting rod due to tension, pressure and torsion requires the connecting rod to be designed with high strength and low weight. With the high-quality product range from Maxpeedingrods, you are always on the safe side.

Application

Compatible for Fiat Punto GT 1.4 1.6L Turbo 4340 Forged Steel

Specification

- Performance Con Rods
- Type: Forged 4340 aircraft chrome moly quality steel for racing
- H-beam Conrods Quantity: 4 Pieces as showing in picture
- Bolts: Including ARP 2000 bolts
- Note: Extra cost for upgrading to ARP L19 bolts
- Bolts Size: ARP 2000 3/8" bolts
- Tolerance: Balanced to +/- 1 gram in set
- Piston Bolt Hole: +-4/1000mm
- Advertised Horsepower Rating:200HP/piece
- Strength of the fastening (PSI): 200,000/230,000 PSI Torque: 48ft ≈ 65 NM
- Top acceleration: 7000-9000rpm
- Warranty: one year warranty for any manufacturing defect

Dimensions

Center to center length: 128.52mm/5.06"
Big end diameter: 48.63mm/1.9145"
Small end diameter: 22mm/0.866"
Big end width: 25.40mm/1.0"
Small end width: 25.40mm/1.0"

Feature

1. TüV Certification Con Rods;
2. Material: Forged SAE 4340 Chrome Moly Steel for the highest strength and durability, dedicated for Racing;
3. Genuine ARP 2000 bolts ,Optional ARP L19 fasteners available as an upgrade;
4. H-Beam design reduces weight without compromising strength;
5. Heat-treating & Shot-peened for remained consistent and strong. Shot-peened finish to remove potential for stress risers;
6.100% CNC machined,Precision rod cap alignment dowels;
7. Bores finished to +/- .01 mm;
8. Balanced to within +/- 1 g per rod;
9. Each rod is magnetic particle tested to ensure free of flaws;
10.100% X-rayed, sonic tested;
11. Custom Service.

Note

- Professional installation is highly recommended (No Instruction Included)
- Custom Service:If there's no conrods you need on our site, we would be happy to help determine your requirements and develop a solution with you to satisfy your needs.
